UDR

UDR

Rig Capacity – > 5,000 ft Maximum Distance Drilled 5,200 ft in 3.5’ coalbed MSHA and PA BDMS Permissible

6015

6015

Rig Capacity – 60,000 lbs push/pull Rotary Torque - 15,000 ft-lb 250 HP Diesel Engine On-board Auto Crane with Umbilical Control

5015 skid and rig

5015 skid and rig

Rig Capacity – 66,000 lbs push/pull Rig Dimensions: (5’ H x 8’ W x 20’ L (mast)) Rig Weight – 6,000 lbs Power Pack (mounted on Cleveland Trailer – 185 HP John Deere Diesel Engine) Triplex Water Pump – FMC 1224M, 120 gpm 2 – 1,000 gallon mix tanks

DB12

DB12

Rig Capacity – 4,000 ft Maximum Distance Drilled 3,775 ft MSHA and PA BDMS Permissible Units

Fletcher

Fletcher

Rig Capacity – > 5,000 ft Maximum Distance Drilled 5,560 ft in 6.5’ coalbed MSHA & PA BDMS Permissible

TD 480 Rig

TD 480 Rig

Designed and Fabricated In-House -Full computer based control system -Capability of accurately controlling bit weight, ROP, rotary speed, rotary torque, auxiliary functions -Fault Management -Touch screen interface -Remote monitoring capabilities via internet -Self-reporting diagnostics -Automatic mitigation of fault conditions with minimal loss of functionality -Full WITS Communication

120

120

Hold-back / Pulldown – 120,000 lbs Derrick Hookload – 180,000 lbs Rotational Torque – 7,000 ft-lbs Derrick Height – 52 feet Mounted on 7’ High Substructure
